4 sets of MG 16T-S:16.6M A5 Double Girder Gantry Cranes & 5 sets of LH10t &15t –S:21.135m A3 & A5 double girder overhead cranes Exported to Philippines

Nov 25,2020
Crane news

Detailed specifications:

1) 4 sets of MG 16T-S:16.6M A5 double girder gantry cranes (A5)

Lifting Capacity: 16t
Span: 16.6m
Lifting height: 5.6m
Lifting mechanism: 16t QD trolley
Lifting speed: 3.6m/min
Trolley traversing speed: 30.5m/min
Crane traveling speed: 3.9-39m/min
Industrial voltage: 440v 60hz 3ph
Work Site: Indoor

2) 2 sets of LH type 10T-S:21.135m double girder overhead crane with integrated hoist trolley (A3)

Lifting Capacity : 10t
Span: 21.135m
Lifting height: 9.6m
Lifting mechanism: 10t integrated hoist trolley
Lifting speed: 7m/min
Trolley traversing speed: 18m/min
Crane traveling speed: 5/20m/min
Industrial voltage: 220v 60hz 3ph
Work Site: Indoor

3) 2 sets of LH type 10T-S:21.135m double girder overhead crane with integrated hoist trolley (A5)

Lifting Capacity : 10t
Span: 21.135m
Lifting height: 9.5m
Lifting mechanism: 10t integrated hoist trolley
Lifting speed: 3.5m/min
Trolley traversing speed: 18m/min
Crane traveling speed: 5/20m/min
Industrial voltage: 220v 60hz 3ph
Work Site: Indoor

4) 1 set of LH type 15T-S:21.135m double girder overhead crane with integrated hoist trolley (A5)

Lifting Capacity : 15t
Span: 21.135m
Lifting height: 9.4m
Lifting mechanism: 15t integrated hoist trolley
Lifting speed: 3.3m/min
Trolley traversing speed: 18m/min
Crane traveling speed: 5/20m/min
Industrial voltage: 220v 60hz 3ph
Work Site: Indoor

Article:

For these cranes, they total needs 11 sets of 40' OH(High open top) containers for delivery, and they were delivered in August, 2020.

For these 4 sets of MG 16t double girder gantry cranes, they are repeated order from our cooperated customer, we have delivered 4 sets of MG 16t double girder gantry cranes and 4 setes of MG 25t double girder gantry cranes to them in 2019.

For 5 sets of 10t and 15t double girder overhead cranes, they are the new project for our customer.

As the working frequency are much heavy, so for the gantry crane, and overhead crane, we choose the A5 design. They are used to lift the steel bars, and the heavy motors, gearboxes, which are for warehouse and production workshops.

Here we want to express our appreciate to our client, they help us to take the installation photo of MG 16t double girder gantry cranes, which were installed in October, 2020. And also thank them for their continous trust and support for about 4 years.

Installation Photo:

Installation Photo

Production Photos:

The main beams for crane are all cut into several pieces, which is easy for delivery. They can be connected by high strength bolts on site.

Double girder overhead crane scaled
Double girder overhead crane 1

Double girder overhead crane scaled
Double girder overhead crane 2

End carraige of overhead crane scaled
End carraige of overhead crane
(For all these cranes, the crane traveling mechanism all apply Boneng three-in-one motor, and the electricals add the frequency converter, then it can achieve double speeds.)

Main beams of double girder gantry crane scaled
Main beams of double girder gantry crane

Support legs of double girder gantry crane scaled
Support legs of double girder gantry crane

Ground beams of double girder gantry crane scaled
Ground beams of double girder gantry crane

Product delivery photos:

Product delivery photos scaled

Product delivery photos scaled

Product delivery photos scaled

Product delivery photos scaled

Product delivery photos

We are looking forward to cooperating with you in the near future and for long time!

END
